Характеристики
| Go!SCAN SPARK™ | |
|---|---|
| Accuracy(1) | Up to 0.050 mm (0.0020 in) |
| Volumetric accuracy(2) (based on part size) | 0.050 mm + 0.150 mm/m (0.0020 in + 0.0018 in/ft) |
| Volumetric accuracy with MaxSHOT Next™ | Elite(3) | 0.050 mm + 0.015 mm/m (0.0020 in + 0.00018 in/ft) |
| Measurement resolution | 0.100 mm (0.0039 in) |
| Mesh resolution | 0.200 mm (0.0078 in) |
| Measurement rate | 1,500,000 measurements/s |
| Light source | White light (99 stripes) |
| Positioning methods | Geometry and/or color and/or targets |
| Scanning area | 390 x 390 mm (15.4 x 15.4 in) |
| Stand-off distance | 400 mm (15.7 in) |
| Depth of field | 450 mm (17.7 in) |
| Part size range (recommended) | 0.1–4 m (0.3–13 ft) |
| Texture resolution | 50 to 200 DPI |
| Texture colors | 24 bits |
| Software | VXelements |
| Output formats | .dae, .fbx, .ma, .obj, .ply, .stl, .txt, .wrl, .x3d, .x3dz, .zpr, .3mf |
| Compatible software (4) | 3D Systems (Geomagic® Solutions), InnovMetric Software (PolyWorks), Metrologic Group (Metrolog X4), New River Kinematics (Spatial Analyzer), Verisurf, Dassault Systèmes (CATIA V5, SOLIDWORKS), PTC (Creo), Siemens (NX, Solid Edge), Autodesk (Inventor, PowerINSPECT) |
| Weight | 1.25 kg (2.7 lb) |
| Dimensions (LxWxH) | 89 x 114 x 346 mm (3.5 x 4.5 x 13.6 in) |
| Connection standard | 1 X USB 3.0 |
| Operating temperature range | 5-40 °C (41-104 °F) |
| Operating humidity range (non-condensing) | 10-90% |
| Certifications | EC Compliance (Electromagnetic Compatibility Directive, Low Voltage Directive), compatible with rechargeable batteries (when applicable), IP50, WEEE |
| Patents | CA 2,600,926, CN 200680014069.3, US 7,912,673, EP (FR, UK, DE) 1,877,726, AU 2006222458, US 8,032,327, JP 4,871,352, EP (FR, UK, DE) 2,278,271, IN 266,573, US 7,487,063, CA 2,529,044, CA 2,810,587, US 8,836,766, JP 5,635,218, CA 2,875,754, EP (FR, UK, DE) 2,751,521, US 9,325,974, CA 2,835,306, CN 201280023545.3, CN 201280049264.5, JP 6,025,830, EP (FR, UK, DE) 2,875,314, CN ZL 201380029999.6, JP 6,267,700, EP (FR, UK, DE) 3,102,908, US 15/114,563, CN 201580007340X |
